VERSE

Visualize Your DMX Universe

Professional passive DMX analyzer with real-time visualization, recording capabilities, and comprehensive channel monitoring.

Key Features

📊 Real-Time Analysis

Monitor all 512 DMX channels simultaneously with instant visualization of signal levels and changes.

👁️ Passive Monitoring

Non-intrusive passthrough design lets you analyze without disrupting your DMX signal chain.

💾 SD Card Recording

Capture DMX data to SD card for later analysis, playback, and troubleshooting.

🔋 Battery Powered

18650 lithium battery with USB-C charging provides hours of portable operation.

📱 Touchscreen Interface

3.5-inch color display with intuitive touch controls for easy navigation.

🔌 DMX Passthrough

Input and output XLR connections maintain signal integrity while analyzing.

Technical Specifications

Display

Size: 3.5 inch
Resolution: 480x320
Type: TFT LCD Touchscreen
Interface: SPI

DMX Interface

Channels: 512 (Full Universe)
Input: 5-pin XLR
Output: 5-pin XLR (Passthrough)
Transceiver: SP485EEN

Power

Battery: 18650 Li-ion
Charging: USB-C
Management: IP5306 IC
Runtime: 4+ hours

Storage

Type: MicroSD Card
Capacity: Up to 32GB
Recording: DMX data logging
Format: CSV / Binary

Perfect For

🎭 Troubleshooting

Quickly identify signal issues, channel conflicts, and timing problems in your lighting rig.

🎬 System Commissioning

Verify proper addressing, patch tables, and signal distribution during installation.

📚 Training & Education

Visualize DMX protocols and demonstrate signal flow for students and trainees.

🔧 Maintenance

Monitor system health, record performance data, and diagnose intermittent issues.
